Базово реле 230 VAC, 2 превключващи контакта, 8A, Wago 788-180

Основни

Nominal input voltage UNAC 230 V

Nominal input current at UN8 mA

Number of changeover/switchover contacts2

Contact material (relay)AgNi 90/10

Limiting continuous current8 A

Inrush current (resistive) max.(AC) 15 A / 4 s

Switching Voltage, Max.AC 250 V

Switching power (resistive) max.AC 2000 VA; DC (see load limit curve)

Switching capacityAC-15: 3 A / AC 250 V; DC-13: 2 A / DC 24 V

Recommended minimum load12 V / 10 mA

Pull-in time (typ.)8ms

Drop-out time (typ.)6ms

Bounce time (typ.)10ms

Electrical life (NO; resistive load; 23 °C)10 x 10³ switching operations

Mechanical life30 x 10⁶ switching operations

Switching frequency with/without load (max.)6 min-1 / 1200 min-1
