Захранване, 1 фаза, Input 85-264 VAC, 60W, 12V Low Profile DIN шина, TDK-Lambda DRL60-12-1

Детайлна информация

InputSingle-phase

Input Voltage Range[AC]85 to 264Vac

Efficiency87% Typ.

Rated Output Voltage[DC]12Vdc

Output Voltage Range[DC]12 to 15Vdc

Maximum Output Current4.5A

Maximum Output Power54W

Package / MountingDIN rail

Width(W)54mm Nom. (2.13in Nom.)

Height(H)91mm Nom. (3.58in Nom.)

Depth(D)55.6mm Nom. (2.19in Nom.)

Weight200g Typ. (0.4lbs Typ.)

Operating Temp. Range-20 to 71°C

CoolingConvection

Safety Standard(Certified)CSA60950-1

UL60950-1

IEC62368-1

UL62368-1

UL508

UL1310 Class 2
