Пресостат FYG 7 bar, регулируема скала 2 прага, 2NC, Telemecanique FYG22 - OsiSense XM

Детайлна информация

Range of productTelemecanique Pressure sensors XM

Pressure sensor typeElectromechanical pressure sensor

Pressure sensor nameFYG

Fluid connection typeG 1/4 (female) conforming to ISO 228

Controlled fluidFresh water (0-70 °C), sea water (0-70 °C)

Cable entry2 cable entries with grommet

Contacts type and composition2 NC snap action

Product specific applicationNot applicable

Pressure switch type of operationRegulation between 2 thresholds

Electrical connectionScrew-clamp terminals, clamping capacity: 1 x 1...2 x 2 mm²

Scale typeAdjustable differential

SettingInternal

Local displayWithout

Electrical circuit typePower circuit

Materials in contact with fluidZinc plated steelnitrilenylon 6/6

Enclosure materialPS

Operating positionAny position

Pressure actuatorDiaphragm

Terminal block type4 terminals

Operating rate10 CYCLE_PER_MINUTE

Terminals description ISO n°1(1-2)NC(3-4)NC

Environment

StandardsIEC 60730CE

Protective treatmentTC

Electrical shock protection classClass I conforming to IEC 536

IP degree of protectionIP20 conforming to IEC 60529
