Електронен сензор за наляганеs XMLG, 0...1 bar, G 1/4 A (мъжки), 24 V, 4...20 mA, set of 1, Telemecanique XMLG001D21 - OsiSense XM

Детайлна информация

Виж продукта в 360°

Range of productTelemecanique Pressure sensors XM

Product or component typeElectronic pressure sensors

Pressure sensor typePressure transmitter

Pressure sensor nameXMLG

Fluid connection typeG 1/4A (male) conforming to DIN 3852-E

Controlled fluidAir (-15-125 °C), corrosive fluid (-15-125 °C), hydraulic oil (-15-125 °C), fresh water (0-125 °C)

Type of output signalAnalogue

Analogue output function4...20 mA, 2 wires

Electrical connection1 male connector M12, 3 pins

[Us] rated supply voltage12 V DC (voltage limits: 8-33 V), 24 V DC (voltage limits: 8-33 V)

Quantity per setSet of 1

Type of packingIndividual

Local displayWithout

Electrical circuit typeControl circuit

Current consumption20 mA

Materials in contact with fluidCeramicFPM (Viton)stainless steel type AISI 303

Operating positionAny position

Protection typeLoad short-circuitreverse polarity

Response time on output< 2 ms

Drift of the sensitivity+/- 0.015 % of measuring range/°C

Drift of the zero point+/- 0.015 % of measuring range/°C

Measurement accuracy+/- 0.3 % of the measuring range

Repeat accuracy+/- 0.1 % of the measuring range

Scale typeFixed differential

Environment

StandardsCEIEC 61326-2-3

Product certificationsCSA C22-2 No 14UL 508

Protective treatmentTC

Vibration resistance20 gn (f= 9-2000 Hz) conforming to IEC 60028-2-6

Shock resistance25 gn for 11 ms conforming to IEC 60068-2-27

IP degree of protectionIP66 conforming to IEC 60529, IP67 conforming to IEC 60529

NEMA degree of protectionNEMA 4
