Telemecanique XCKN2102P20 - OsiSense XC Standard - Краен изключвател с ролково бутало, 1NC+1 NO бързодействащи, M20

Виж продукта в 360°

Range of productTelemecanique Limit switches XC Standard

Series nameStandard format

Product or component typeLimit switch

Device short nameXCKN

Sensor designCompact form C

Body typeFixed

Head typePlunger head

MaterialPlastic

Body materialPlastic

Head materialPlastic

Fixing modeBy the body

Movement of operating headLinear

Type of operatorSpring return roller plunger plastic

Type of approachLateral approach, 2 directions

Cable entry1 entry tapped for M20 x 1.5 cable gland, cable outer diameter: 7-13 mm

Contacts type and composition1 NC + 1 NO

Contact operationSnap action

Switch actuationBy 30° cam

Electrical connectionScrew-clamp terminals, clamping capacity: 1 x 0.34...2 x 1.5 mm²

Contacts insulation formZb

Positive openingWith

Contact code designationA300, AC-15 (Ue = 240 V), Ie = 3 A, Ithe = 10 A conforming to IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to IEC 60947-5-1 appendix A

Terminals description ISO n°1(21-22)NC(13-14)NO

Environment

Shock resistance45 gn for 11 ms conforming to IEC 60068-2-27

Vibration resistance25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6

IP degree of protectionIP65 conforming to IEC 60529

IK degree of protectionIK04 conforming to IEC 62262

Overvoltage categoryClass II conforming to IEC 61140, class II conforming to NF C 20-030

Protective treatmentTC

Product certificationsCSACCCUL

StandardsCSA C22.2 No 14UL 508IEC 60947-5-1IEC 60204-1
