Datasensing SG4-DONGLE - SG4 EXTENDED Ethernet communication interface Box 15 pcs

Детайлна информация

• No dead zone
• Pigtail cable with M12 connector
• Cascade connection of up to 3 units
• Up to 20m operating range and 1800m protected height
• Compact dimensions (35 x 41 mm section)
• Anti-interference coding
• Integrated Muting function
• Floating Blanking, Fixed Blanking and Reduced Resolution
• Configurable with:
• Pushbuttons for common configuration
• Graphic User Interface for complete parametrisation
• Ethernet Interface for programming, monitoring and error logging

Detection properties

Nominal sensing distancen/a

Resolutionn/a

controlled heightn/a

number of raysn/a

Sensitivity adjustmentn/a

Effective Aperture Anglen/a

Application

DescriptionEthernet adapter (15 pcs)

FunctionsSG4 Programmable Ethernet adapter

Safety parameters

TypeSafety accessory

SILn/a

SILCLn/a

Outputs

Output typen/a

Response timen/a

Electrical data

Operating Voltagen/a

Load current≤ 500mA each output

Emissionn/a

Interference to external lightn/a

Power Consumption - Receivern/a

Power Consumption - Emittern/a

Mechanical data

Dimensionsn/a

Materialn/a

ConnectionsM12-12 poles + M12-5 poles + M12-4 poles D-Coded

Generical Data

Network InterfaceEthernet TCP/IP

Dimensionsn/a

Humidity15 … 95 % (no condensation)

Mechanical ProtectionIP65

UNASSIGNED

Disegno 2D PDFn/a
